Panel | Dimension | 43/49/55 inch LCD screen |
Capacitive touch screen | 10 points capacitive touch screen |
Writing method | Finger or stylus |
Resolution | 1920×1080 |
Screen scale/Display area | 476.64mm * 268.11mm |
Display color | 16.7M |
Visual angle | H：176° V：176° |
Brightness | 250 cd/m2 |
Contrast | 1000:1 |
Response time | 5ms |
Screen Life(hrs) | > 50,000(hrs) |
Configuration | CPU | RK3288 |
Memory | 2G DDR3 |
Storage | 8GB Normally, EMMC NAND chip can be extended up to 32GB |
OSD language | Multi language support |
System | Android 7.1 |
Network | Ethernet | 10M/100M |
WiFi | 802.11 b/g/n |
Bluetooth | Support V2.1+EDR/BT v3.0/BT v3.0+HS/BT v4.0 |
Interface | USB Port | USB 2.0 |
RJ45 | 10M/100M |
TF Card | Push-push type TF socket, support at most 32GB TF card |
Multi-Media | Video | Support MPEG-1, MPEG-2, MPEG-4, H.263, H.264, RV, etc. (max support 1080P) |
Audio | Support MP4，WMA, AAC and so on |
Picture | JPEG, PNG, BMP and so on |
Power | The input voltage | AC100-240v 50/60HZ |
Standby power | ≤1W, support low power standby mode |
Other parameters | Material | Metal case |
Speaker | 2×6W speakers (8Ω) |
Color | Black Normally, OEM support |
Installation | Wall mounted on the floor standing |
Operating temperature/humidity | 0℃~50℃/20%～80% |
Store temperature/humidity | -10℃~60℃/5--95% |
Software support | Free installation applications (maps, games, e-mail, self developing apps, etc.) |
Attachment | Adapter | One |
Warranty card | One |
Qualification certificate | One |
User's Manual | One |
Screw and Key | One |
Antenna | One |
